Powerful Expansion Capabilities

This server is designed to offer extensive expansion options, ensuring it meets diverse and evolving needs. It supports up to 16 x 3.5-inch hard drives or up to 28 x 2.5-inch hard drives or E3.S drives. It includes 10 standard PCIe slots and 1 OCP 3.0 slot, providing ample space for additional expansion cards. The server can accommodate up to 4 dual-width GPUs or 8 single-width GPUs, making it ideal for high-performance and computationally intensive tasks.

Expansion Features:

Storage: Supports up to 16 x 3.5-inch hard drives or 28 x 2.5-inch hard drives or E3.S drives; includes 2 M.2 SSD slots.

PCIe Expansion: Up to 10 standard PCIe slots and 1 OCP 3.0 slot.

Prise en charge des GPU : Jusqu'à 4 GPU double largeur ou 8 GPU simple largeur.

Reliable Performance Assurance
The server ensures robust performance with support for up to 225W CPUs and up to 16 DIMM DDR5 memory slots, meeting the needs of mainstream applications. It supports CXL memory expansion, allowing for scalable and large memory capacity based on demand. Additionally, it utilizes PCIe 5.0 protocol for enhanced data transfer speeds and improved overall system performance.

Performance Highlights:

High-Performance CPUs: Supports up to 225W Intel  Xeon  4th Generation Scalable processors.

Advanced Memory: Up to 16 DDR5 DIMM slots per CPU, with CXL memory expansion support.

PCIe 5.0 Support: Provides faster data transfer rates and improved performance.

Cost-Effective Product Solution
This server is designed to offer an excellent balance of performance and value. It features a meticulously designed board layout and materials to ensure high efficiency and reliability. The onboard network options are chosen for their cost-effectiveness, making this server a highly competitive choice in terms of price and performance.

Cost-Effectiveness Features:

Board Design: Optimal design for enhanced performance and reliability.

Network Options: Cost-effective onboard network solutions for better value.

Spécifications techniques

Model: [Model Name]

Processeurs :

1/2 Intel Xeon  4th Generation Scalable processors, TDP 225W

Mémoire :

Up to 16 DDR5 DIMM slots, 8 memory channels per CPU

Stockage :

Jusqu'à 12 disques durs de 3,5 pouces

Jusqu'à 28 disques durs de 2,5 pouces ou E3.S

Prise en charge de 2 disques SSD M.2

Expansion PCIe :

Jusqu'à 10 emplacements PCIe standard

1 emplacement OCP 3.0

Prise en charge du GPU :

Jusqu'à 4 GPU double largeur ou 8 GPU simple largeur

Gestion :

AST2600 BMC

1 port de gestion RJ45 Gigabit

Ports E/S :

2 x USB 3.0 Type-A en façade

2 x USB 3.0 Type-A à l'arrière

1 x bouton d'alimentation avec LED

1 x Bouton UID en façade avec LED

1 x LED UID arrière

1 x VGA avant

1 x VGA arrière

Refroidissement :

4 ventilateurs haute performance remplaçables à chaud avec redondance N+1

Refroidissement par plaque froide en option

Température :

Fonctionnement : 5oC - 35oC

Étendue : Jusqu'à 45oC (configurations spécifiques)

Puissance :

2 alimentations CRPS avec redondance 1+1

Dimensions :

840 mm (L) x 447 mm (P) x 86 mm (H)
