Fitur Produk

Balanced Configuration with Exceptional Cost-Effectiveness

Processor: Supports a single AMD EPYC  9004 series processor with up to 320W TDP, delivering powerful computational performance for a wide range of workloads.

Memory: Supports 12 DDR5 memory slots with up to 4800MHz frequency, offering a 50% increase in memory bandwidth to meet demanding application requirements.

ATX Standard Design: The server is built on the ATX standard board, balancing performance and cost, providing exceptional value while meeting mainstream workload needs.

Flexible Configuration and Expansion

Storage Options: Flexible storage module choices, compatible with 3.5″ and 2.5″ drives, and supporting NVMe, SAS, and SATA configurations.

NVMe Support: Accommodates up to 4 U.2 NVMe SSDs to ensure it meets the needs of mainstream applications.

PCIe Expansion: Offers up to 5 PCIe 5.0 x16 expansion slots, ensuring future-proof expansion options for various peripherals and high-speed upgrades.

Stability, Reliability, and Intelligent Management

Redundancy and Hot-Swappability: Key system components feature redundancy and hot-swap capabilities, ensuring high availability and ease of maintenance. Tool-less design enhances fault maintenance efficiency.

Smart Management: The system integrates intelligent management chips, supporting IPMI 2.0, Redfish, and SNMP protocols for open, versatile management.

Remote Management: Comprehensive remote system management includes KVM, virtual media, component status monitoring, and alert functions for reliable, real-time system oversight.

Spesifikasi Teknis

Prosesor:

Supports 1 AMD EPYC  9004 series processor

Maximum TDP: 320W

Memori:

12 DDR5 memory slots (1DPC)

Maximum frequency: 4800MHz

Jenis memori: RDIMM, 3DS RDIMM

Maximum capacity: 3TB

Pengontrol Penyimpanan:

Pengontrol SATA 6Gb/s terintegrasi

Pengontrol SAS HBA dan RAID 12Gb/s opsional

Penyimpanan Lokal:

Depan: Mendukung drive hingga 12 x 3,5 inci, dengan opsi 8 x 3,5 inci

Belakang: Mendukung drive 2 x 2,5 inci

Internal: 1 x M.2 (SATA 3.0 / PCIe 4.0 x4, 2280 & 22110)

Maximum: 4 x U.2 NVMe SSDs

Ekspansi PCIe:

Supports 5 PCIe 5.0 x16 expansion slots

Jaringan:

1 x 1Gb RJ45 port manajemen khusus

2 x 1Gb port data RJ45 dengan dukungan NCSI

Pelabuhan:

Depan: 1 x VGA, 2 x USB 3.0

Belakang: 1 x VGA, 4 x USB 3.0, 1 x port manajemen RJ45, 1 x port COM, 2 x port data RJ45 1Gb

Fitur Manajemen:

Chip manajemen BMC terintegrasi (AST2600)

Mendukung IPMI 2.0, Redfish, SOL, KVM, media virtual

1Gbps RJ45 dedicated management port

Fitur Keamanan:

Modul keamanan TPM/TCM opsional

Deteksi intrusi sasis

Penutup atas sasis yang dapat dikunci

Catu Daya:

Dapat dikonfigurasi dengan 2 modul daya (1+1 redundansi, dapat ditukar dengan hot-swappable)

Opsi masukan: 220V AC, 240V DC

Peringkat daya: Efisiensi 800W atau 1300W Platinum

Sistem Pendinginan:

Supports 3 hot-swappable fan modules with N+1 redundancy

Kontrol kecepatan kipas yang cerdas dan kemampuan alarm yang tidak normal

Dimensi Sasis:

Lebar: 448mm x Tinggi: 87mm x Kedalaman: 660mm (680mm termasuk telinga)

Kisaran Suhu:

Suhu pengoperasian: 5oC - 35oC (tanpa sinar matahari langsung)

Storage temperature: -40oC – 70oC

Kisaran Kelembaban:

Pengoperasian: 8% hingga 90% (tanpa kondensasi)

Penyimpanan 5% hingga 95% (tanpa kondensasi)

Dukungan Sistem Operasi:

Microsoft Windows Server

Server Microsoft Hyper-V

Red Hat Enterprise Linux

SUSE Linux Enterprise Server

CentOS

Ubuntu

Oracle Linux

VMware ESXi

Citrix XenServer

Mengapa Memilih Kami?

Kinerja yang Hemat Biaya

High Value: Delivers powerful processing and memory capabilities at an affordable price, perfect for mainstream workloads.

Scalable Expansion

Future-Proof Design: With multiple PCIe 5.0 slots and flexible storage configurations, it adapts to growing data demands and changing business needs.

Reliable Operation and Smart Management

Fault-Tolerant Design: Redundant power, hot-swappable fans, and smart management features minimize downtime and improve serviceability.

Intelligent Monitoring: Remote management tools ensure you can monitor and manage the system efficiently from anywhere.
